12 ft minipro aluminum alloy telescopic crane, the world's lightest high-payload cinema telescopic arm.
One-piece aviation aluminum alloy arm body, arm body 37 kg.
Overall length: 16.4 ft (5 m); with fixed extension arm: 19.7 ft (6 m).
Front arm length: 12 ft (3.65 m); with fixed extension arm: 15.2 ft (4.65 m)
Rear arm length: 4.75 ft (1.45 m).
Transport length: 12.8 ft (3.9 m); 4.1 m with outer flight case.
Key Features:
Electronic direct-drive leveling head and electric worm-gear automatic leveling head optional;
Maximum payload: 25 kg;
Maximum speed: 1.5 m/s;
3-section, 2-stage telescoping, can be equipped with a 1 m fixed extension arm;
Maximum underslung height from ground: 4.67 m;
Dedicated rail-wheel lifting four-wheel dolly, electric lifting height: 0.45 m;
Flexible A/B point soft limit settings;
7 levels of electronic damping can be set;
Standard Mitchell mount base interface;
Unique V-mount battery power and 220V AC adapter power supply;
Total weight (including counterweights): 69 kg;
Technical Specifications
