12 ft mini aluminum alloy telescopic crane, the world's lightest cinema telescopic arm.
One-piece aviation aluminum alloy arm body, arm body 25 kg.
Overall length: 16.4 ft (5 m).
Front arm length: 12 ft (3.65 m).
Rear arm length: 4.4 ft (1.35 m).
Transport length: 12.8 ft (3.9 m); 4.1 m with outer flight case.
Key Features:
Gravity self-swing damping leveling head;
Maximum payload: 12 kg;
Maximum speed: 1.2 m/s;
3-section, 2-stage telescoping, integrated arm body guide rail;
Maximum underslung height from ground: 4.67 m;
Flexible A/B point soft limit settings;
Electronic damping can be set;
Standard Mitchell mount base interface;
Unique V-mount battery power supply;
Total weight (including counterweights): 59 kg;
Technical Specifications
